100 T/H Cement Rotary Kiln

Place of Origin : Henan, China

Supply Ability : 500 Set/Sets per Year rotary kiln

Packaging Details : Standard packing or according to customer's requirement

MOQ : >=1 Sets

Price : $20,000.00

Warranty : 1 YEAR

Applicable Industries : Manufacturing Plant, Construction works , Energy & Mining

After Warranty Service : Video technical support, Online support

Condition : New

After-sales Service Provided : Online support, Field installation, commissioning and training

Weight : 1648 T

Color : Support Customized

Output : 80-100 T/H(roasted sand)

Power consumption : 650kWh/t

Port : QingDao,ShangHai,TianJin

Contact Now

Complete Production Line laterite nickel furnace calcination rotary kiln

Product Description

Name	laterite nickel furnace calcination rotary kiln
Equipment name	Rotary kiln
Specification	Φ5.5×115m
Application	Roasting laterite ores
Amount	1Set
Output	80-100(roasted sand)t/h
Driving mode	Double driving
Type of thrust roller	Hydraulic thrust roller
No. of support	4
Slope ( sine)	3.0%
Driving mode	Bilateral double-driving
Main driving	0.2~1.2r/min
Auxiliary driving	6.7r/h
Sealing mode of kiln head	Sheet steel (provisional)
Sealing mode of kiln end	Air cylinder
Cooling of kiln head	Air cooling
Rotating direction	Clockwise (from discharging end)
Total weight	1648 ( excluding feed and discharge cover)t
Temperature of discharged materials	750~850°C
Temperature of waste gases	200~400°C
Thickness of refractory bricks	230mm

Description of Lateritic Nickel Rotary Kiln:
Our lateritic nickel rotary kiln is mainly used to smelt lateritic nickel ores so as so get nickel pig iron. So far CITIC HMC Co., Ltd has successfully carried out many projects in China, such as Guangqing in Guangdong Province, Dingxin in Fujian Province, Qingshan in Zhejiang Province, Linyi in Shandong Province, and more.
LUOYANG ZHONGTAI Lateritic Nickel Rotary Kiln technical characteristics:
♦ Kiln body is made of high quality composed of carbon steel or alloy steel plate and automatic welding;
♦ Tyre,Support Roller,Open gear adopts alloy cast steel;
♦ Sliding bearing with large gap not scraping tile bearing;
♦ Transmission device adopts hard tooth surface reducer, flexible diaphragm coupling, dc motor;
♦ Adopts hydraulic gear wheel;
♦ Preheater scales were used respectively to veiw of kiln head, and cylinder pressure tight seal;
♦ A slow drive device.

FAQ

Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.

Q:Delivery time
A: parts lead time 1-2months, machines 2-3months.

Q:Payment terms
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping

Q: Quality warranty?
A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.

Q: After sales service?
A: we can supply technical guide for machines running test and parts maintenance if end user needs.
